江苏晨光数控机床有限公司 · Taixing, Jiangsu

Chenguang thread whirling & grinding

A six-metre whirling operation and a 1500 mm thread-grinding operation are different stages. Compare CGK-401 and CGK-1500 from the thread drawing, material condition and inspection target.

Official company and original model tables reviewed 8 October 2026

What must this machine do to the thread?

Whirling cuts with a rotating cutter head; grinding finishes with a dressed wheel. Neither process can be chosen from component length alone.

Forming a long threaded section

Investigate CGK-401 from blank diameter, material/hardness, thread form, helix and support positions. Specify the cutting stage and what allowance remains for subsequent operations.

Grinding the required profile

Investigate CGK-1500 from the thread form, pitch, starts, support arrangement and finish/lead target. Its official description covers ball-screw, trapezoidal and other thread profiles.

A route can contain both operations, but these two listings do not establish a compatible production line. If heat treatment or further finishing lies between them, define the allowance, distortion and datums at every transfer.

Keep the diameter and length definitions intact

Named model columns from the original tables. CGK-402/404 figures are not transferred into CGK-401.
ConstraintCGK-401 whirlingCGK-1500 grinding
Published length6000 mm maximum machining length1500 mm thread-grinding length; 1600 mm center distance
Diameter condition160 mm maximum mounting diameter; milling 20–120 mmDisc-type work up to 360 mm; with steady rest up to 160 mm
Minimum grinding diameterNot a grinding model12 mm; 6 mm by special order
Helix / starts±20° / 1–24±25° / 1–99
Published rotationsWork 0–20 rpm; head 500–2000 rpmWork 0–150 rpm; wheel 1000–3000 rpm
Metric thread pitchConfirm for the requested profile/tool1.5–48 mm

Swipe the comparison sideways on a narrow screen.

Official CGK-401-marked thread-whirling machine image

CGK-401: clamp size is not cutting size

The exact column lists a 160 mm mounting diameter but a 120 mm maximum milling diameter. Show the root/crest dimensions, thread length, chuck datum and supports before treating a mounted blank as machinable.

Open CGK-401 specifications ↗
Official Chenguang CGK-1500 thread grinder image

CGK-1500: support changes the diameter limit

A 360 mm disc-type limit does not establish a 360 mm shaft capacity with a steady rest. The latter row states 160 mm. Plot the wheel, support and all shoulders over the 1500 mm grindable thread section.

Open CGK-1500 specifications ↗

Prove the loaded thread path

Send an assembly drawing of the blank, chuck/centers and each steady support. Identify interrupted sections, shoulders and run-in/run-out space. For a long whirled screw, ask how support moves through the cutting sequence; for grinding, show the wheel approach and dressing clearance.

Keep pitch, lead and starts separate

Specify all three, plus thread hand and profile. A multi-start thread's lead is not simply its pitch. Have the proposal identify the programmed motion, cutter/wheel profile and measurement definition for the drawing.

Request the exact control package and licensed threading/compensation functions, cutter or wheel, dressing, coolant, chip removal, gauging and support accessories. A catalog control choice or closed-loop arrangement alone does not establish the accepted thread result.

Turn the thread drawing into a sample report

Geometry

Nominal/root/crest diameters, profile, pitch, lead, starts, hand, helix, thread length and support datums.

Starting condition

Alloy, heat treatment, blank straightness, stock allowance, mass and dimensions before this operation.

Measurement

Agreed lead/profile, runout and roughness methods; measurement span, locations, temperature and sample quantity.

Repeatable process

Tool/wheel and dressing state, supports, operating settings, adjustment interval and complete handling/inspection cycle.

The original CGK-1500 table distinguishes a lead-related claim over one revolution from one over any 300 mm. CGK-401 also publishes separate spans. Request the exact test definition and evidence for the offered part; do not collapse those claims into one universal accuracy or compare them with axis resolution.

Dedicated machines from Taixing

The official account identifies Jiangsu Chenguang CNC Machine Tool in Taixing and describes dedicated/combination CNC machines, flexible automated lines and remanufacturing. Its catalog includes graphite/carbon processing and functional-component equipment. The two reviewed thread machines represent one part of that range; their ratings do not apply to the other equipment.

The national record for GB/T 43201.3-2023 lists the exact entity as a drafting organization. Published 7 September 2023, it concerns information flows in production planning; it is not certification of either thread machine.

Request a route for your screw drawing

Attach the thread drawing, starting condition, support assembly and inspection brief above. Ask for the selected operation, exact machine/configuration, tooling and a measured representative trial.

Prepare a Chenguang RFQ ↗
