Longchang · 3-axis machining
Longchang LC-700NC
LC-700NC is Longchang’s larger standard twin-head reference for 30 × 30 to 700 × 700 mm blocks. Its 240 mm maximum listed thickness and 250 mm cutter match the LC-600NC entries, while its 500 × 500 mm table and 1500 kg listed load provide different workholding limits. Check the loaded fixture and lifting route for the actual blank.
The current Chinese standard page gives 10–750 rpm and a 15 kW spindle-motor entry. X/Y movements belong to the two spindle heads, at 380 mm each; the moving table has 950 mm travel. All three rapid entries are 10000 mm/min, equivalent to 10 m/min. Neither spindle rating nor rapid speed establishes finished-part accuracy or production cycle.
This record uses the clean original image from the standard LC-700NC page. The stronger-version photo and its promoted cutting depth are separate evidence. Demonstrate allowance removal, indexing and measurement on the required material, then inspect both face pairs and their squareness after unclamping.
Catalog specifications
- Processing size
- 30 × 30 to 700 × 700 mm
- Maximum listed thickness
- 240 mm
- X right-head / Y left-head / Z table travel
- 380 / 380 / 950 mm
- Worktable
- 500 × 500 mm
- Listed table load
- 1500 kg
- Cutter diameter
- 250 mm
