FEELER · 3-axis machining

FEELER VMP-30

VMP-30’s current FEELER column lists X/Y/Z travel of 760/420/510 mm, an 890 × 420 mm table and a 300 kg maximum table load. The 420 mm Y travel and table width make the loaded fixture and clamp position important; the longer table does not mean that every point on its surface is reachable by the spindle.

The same column lists 10,000 rpm, No.40 taper, 18 tools and X/Y/Z rapid rates of 36/36/36 m/min. Confirm controller, spindle duty, holder/retention system and occupied tool limits. The current series image is marked VMP-30A, so it is not approved here as an exact photograph of the retained unsuffixed VMP-30 build.

Include the part, clamps, fixture and any rotary equipment in the load and reach checks. Trial the highest or furthest feature with the actual holder and material, measure the part after release and record loading-to-unloading time. FEELER brand documentation is separate from proof of the actual Hangzhou builder or legal seller; establish both on the quotation.

Catalog specifications

X / Y / Z travel (mm)
760 / 420 / 510
Table dimensions (mm)
890 × 420
Maximum table load (kg)
300; include fixture
Spindle speed (rpm)
10,000; duty/package to confirm
Spindle taper
7/24 No.40; holder/retention to confirm
Tool count
18; occupied tool limits to confirm

Additional specifications

X / Y / Z rapid rates (m/min)
36 / 36 / 36

Figures come from the manufacturer's model material. Confirm the selected options in your RFQ.
