PHISONG VG-600

Grinding · Jiangsu Feixiang CNC Equipment Co., Ltd.

Catalog figures — see source review
Internal grinding diameter, first range100–180 mm
Maximum bore-grinding length, first range400 mm
Internal grinding diameter, second range180–580 mm
Maximum bore-grinding length, second range500 mm
Maximum workpiece outside diameter for bore grinding600 mm
Maximum external grinding diameter600 mm
PHISONG VG-600 manufacturer image

PHISONG VG-600 official product image; confirm the supplied configuration.

PHISONG VG-600 is a vertical grinding machine with a 600 mm rotary table and a published 500 kg table-load rating. The detailed specification covers internal bores as well as external cylindrical surfaces. Maximum external grinding diameter is 600 mm, and the workpiece outside diameter must remain within 600 mm for the listed bore-grinding ranges.

Bore diameter changes the permitted grinding depth. For bores from 100 to 180 mm, the stated maximum internal grinding length is 400 mm; for bores from 180 to 580 mm, it is 500 mm. These paired limits are more specific than the general capacity figures at the top of the catalog page and must be checked together.

The maximum table speed is 250 rpm. Provide a section drawing showing bore steps, shoulder access, clamping surfaces and the complete workpiece-and-fixture mass in the RFQ. Confirm the grinding spindle, wheel reach, dressing method and inspection procedure for each surface. At the shared 180 mm range boundary, obtain a configuration-specific confirmation rather than assuming the deeper reach applies.

Can every bore be ground 500 mm deep?

No. The detailed table limits 100–180 mm bores to 400 mm and lists 500 mm for the 180–580 mm range. Confirm the boundary case and wheel clearance.

Same listing
FX32-500
M1080B
M400

Additional specifications

Rotary-table load
500 kg
Maximum rotary-table speed
250 rpm
Rotary-table diameter
600 mm

Figures come from the manufacturer's model material. Confirm the selected options in your RFQ.
