PHISONG's centerless, cylindrical and vertical grinders locate the part differently. Start with the datum and geometry, then compare the four exact machine records.

Company and four official model pages reviewed 8 October 2026

Brand / Chinese entity
PHISONG / 江苏飞象数控设备有限公司
Published location
Huishan, Wuxi, Jiangsu
First drawing check
Support, shoulders and inspection datum

Follow the part's locating method

A process shortlist, not a guarantee that every drawing fits the machine.
Part and datum questionInvestigateShow on the drawing
Outside surface supported by wheels and workrestM1080B / M400 centerlessThrough-feed path or plunge feature; shoulders, taper, allowance and entry/exit support
Shaft supported between centersFX32-500 cylindricalCenter holes, driven datum, journal locations, mass and steady-rest needs
Bore/OD with vertical table workholdingVG-600 verticalClamp/datum scheme, bore diameter/depth, outside envelope and wheel access

Swipe the process map sideways on a narrow screen.

A diameter common to two ranges does not make the setups equivalent. Choose from the datum that must be maintained and the surfaces that can support the blank without obstructing the grind.

Through-feed or plunge: check the shape first

The M1080B description separates through-feed cylindrical work from manual plunge grinding of stepped, tapered and cylindrical surfaces. Show shoulders and end features before assuming the part can pass continuously through the setup.

Diameter is published for both operating modes; the 140 mm length belongs only to M1080B plunge grinding.
Recorded limitM1080BM400
Through-feed / plunge diameter5–80 mm / 5–80 mm5–200 mm / 5–200 mm
Maximum plunge length140 mmNot stated in the reviewed table
Grinding wheel500 × 150 × 305 mm600 × 400 × 305 mm
Grinding-wheel motor15 kW30 kW
Regulating wheel speed10–200 rpm10–200 rpm
Official PHISONG M1080B centerless grinder image

M1080B: qualify the supported profile

Include the workrest/blade, regulating-wheel setup and loading arrangement in the proposal. The 0.0025 mm handwheel graduation describes a feed setting; it does not promise a 0.0025 mm finished tolerance.

M1080B exact model data ↗
Official PHISONG M400 centerless grinder image

M400: wider wheel, different installation demand

The table lists 200 L/min coolant flow and approximately 9,000 kg machine mass. Request the tank, filtration, heat management and handling scope for the actual duty. Its 0.001 mm main-feed increment also remains a setting, not a part-accuracy result.

M400 exact model data ↗

Do not infer M400 plunge length from its 400 mm wheel width. Submit the entire grind width/profile and dressing requirement for an application-specific confirmation.

FX32-500: preserve the shaft datum

Official PHISONG FX32-500 cylindrical grinder image

320 mm diameter · 500 mm grinding length

The record separately limits workpiece weight between centers to 150 kg and lists 180 mm center height. The 600 × 75 × 305 mm wheel is rated at a published 35 m/s peripheral speed.

FX32-500 capacity and wheel data ↗

For a shaft, show center-hole condition, drive arrangement, shoulders, journals and the inspection datum. Ask whether a steady rest or another support is needed and confirm wheel access beside each shoulder. A part inside the diameter/length envelope can still need a different fixture or sequence.

VG-600: keep bore diameter and depth together

Official PHISONG VG-600 vertical grinder image

Two internal-grinding envelopes

Ø100–180 mm bores: maximum 400 mm grinding length. Ø180–580 mm bores: maximum 500 mm length. Both rows require workpiece outside diameter ≤600 mm.

Maximum external grinding diameter is 600 mm; table load is 500 kg, table diameter 600 mm and maximum table speed 250 rpm.

VG-600 linked capacity data ↗

Use the detailed bore table: the source page's headline also displays a 600 mm “maximum grinding length,” but its internal-grinding rows specify 400 or 500 mm depending on diameter. Do not quote 600 mm as a universal bore depth. Confirm the exact head, wheel, approach and loaded fixture.

A ring/disc RFQ should include bore/OD concentricity, datum faces, clamp pressure/contact surfaces and part-plus-fixture mass. Check how the part is located and measured after unclamping, not only on the rotary table.

Include dressing, handling and measurement in the trial

Request one reproducible process record

  • Incoming material/hardness, stock allowance, drawing revision and support/fixture.
  • Wheel and dressing method, regulating-wheel or workhead settings, coolant and filtration.
  • Finished size, roundness/cylindricity, datum relationship and texture at agreed locations.
  • Results across a stated sample run, thermal condition and interval between dressing/adjustments.
  • Complete cycle with loading, unloading, inspection and any automation included.

For automation, define what the feeder, gripper and gauge must detect and how rejected or misloaded parts are handled. The company's automation offering is not a statement that every pictured grinder includes those devices.

PHISONG is Jiangsu Feixiang's grinding brand

The official account identifies Jiangsu Feixiang CNC Equipment in Wuxi and publishes centerless, cylindrical, vertical, compound grinding and polishing equipment. Its company material shows guideway grinding and inspection instruments including roughness, diameter, coordinate and cylindricity measurement. These are attributed manufacturer descriptions; no independent factory audit or unverified certification badge is implied.

The 2025 Jiangsu first-batch technology-SME list, hosted by Ganyu government, includes the exact entity in Wuxi (entry 9362). That dated company record is not certification of a grinder or its finished-part result.

The four model pages were individually revisited on 8 October 2026. The wider catalog and handling solutions require their own application review; ratings are kept with the named machine and operating mode.

LOCATE · GRIND · MEASURE

Send the part and its datum scheme

  • Drawing, material/hardness, incoming sizes and grinding allowance.
  • Support surfaces, center holes or clamp scheme, shoulders and bore depth.
  • Finished size/form/texture and the measurement method.
  • Volume/mix, dressing strategy, handling/gauging scope and destination.
